Integral Drill Steel-L800 D34

Rock drilling tools ProDrill provides a variety of integral drill steel and plug hole rods in a full range of lengths and steel hex diameters for all of your hand-held pneumatic drilling needs.

Integral drill rod‘s shank sizes 82.5 mm*22mm(3 1/4”*7/8”), 108mm*22mm(4 1/4”*7/8”), 108mm*25mm(4 1/4”*1”), 159,*25mm(6 1/4”*1). Lengths: 400mm to 6400mm(1’4”-21’). Head diameters: 27mm to 40mm.

Integral drill rod, another name called integral drill steels, integral rods are used by hand held rock drill in granite and marble quarries, underground mining, for small blasting hole drilling shank H22x108mm, H19x108mm, and standard hex. Bit diameters include 20-42mm,different lengths are available from 400mm to 6000mm usually.

It can reduce the expense of impact energy, improves the drilling speed and efficiency, also it can be used for drilling bore hole diameter from 30mm to 41mm usually. Each rods use premium quality alloy steel and excellent quality tungsten carbide to assure.

On request, we can supply integral and plug hole rods to custom lengths and gauges. At rock drill bits ProDrill, we use the finest raw materials available, including premium steel and top quality carbide.

Dia. 20 mm integral drill rod for Y6 ,Y8,Y10 for stone work ,

For more details please watch PDF online:  Integral Drill Steels for Small Hole Drilling Catalogue

Integral Drill Steel

For more details please watch PDF online: Integral Drill Steels for Small Hole Drilling Catalogue
